CJK6136A/6140A×750 economical CNC Lathe
1. Technical parameters
|
Specifications | |
|
Max.swim over bed |
Φ360mm/400mm |
|
Max.swim over carriage |
Φ200mm/220mm |
|
Max.length of work piece |
750mm |
|
Range of spindle speed |
25-1600rpm 12grade |
|
Spindle bore |
Φ46mm |
|
Taper of spindle bore |
MT6 |
|
Stations of tool carrier |
|
|
Min.setting unit of motor |
(Z) long 0.001mm，(X) cross 0.001mm |
|
Moving speed of post |
(Z) long 8 m/min，(X) cross 6 m/min |
|
Taper of taikstock quill |
MT4 |
|
Max.range of tailstock quill |
120mm |
|
Motor power |
4/5.5KW |
|
Packing size（lenght×width×height） |
2050 mm×1250 mm×1600mm |
|
Net weight |
1700kg |
2.Features
1. 12 grades conversion stepless speed regulation, wide speed range, high efficiency, high precision, energy saving.
2. simple,High Quanlity & Reasonable Price, economical and practical.
3.Uses
uses for steel, cast iron and other coarse materials, vehicles and precision machining.
